Power your gaming PC or high-performance workstation with the ASUS PRIME 750W GOLD, a reliable and efficient power supply designed for modern PC builds. With 80 PLUS Gold efficiency, ATX 3.0 compatibility, and a fully modular cable design, it delivers stable power while helping keep your system cool, quiet, and organized.
# of #
| Specification | Details |
|---|---|
| Model | AP-750G |
| Form Factor | ATX12V |
| ATX Standard | ATX 3.0 |
| Total Output | 750W |
| Efficiency Certification | 80 PLUS Gold |
| PFC Type | Active PFC |
| AC Input Range | 100–240V AC |
| DC Output Voltage | +3.3V, +5V, +12V, -12V, +5Vsb |
| Protection Features | OPP / OVP / UVP / SCP / OCP / OTP |
| Hazardous Materials Compliance | RoHS |
| AURA Sync | No |
| 0dB Fan Technology | No |
| MTBF | >120,000 hours @ 25°C |
| Dimensions | 150 × 150 × 86 mm |
| Weight | 1.466 kg (PSU only) |
| Rail | +3.3V | +5V | +12V | -12V | +5Vsb |
| Maximum Load | 20A | 20A | 62A | 0.3A | 2.5A |
| Combined Load | 110W | 110W | 744W | 3.6W | 12.5W |
Total Power Output: 750W
