Brand
Thermaltake
Model
PS-TPG-0750FPCGUS-R
Series
Toughpower Grand RGB Gold
Type
Intel ATX 12V 2.4 & SSI EPS 12V 2.92
Maximum Power
750W
Fans
1 x 140mm Hydraulic Bearing Fan
Fan LED
RGB
PFC
Active
Main Connector
24Pin
+12V Rails
Single
PCI-Express Connector
4 x 6+2-Pin
SATA Power Connector
9
SLI
SLI Ready
CrossFire
CrossFire Ready
Modular
Full Modular
Power Good Signal
100-500ms
Hold-up Time
16ms min.
Efficiency
90%
Energy-Efficient
80 PLUS GOLD Certified
Over Voltage Protection
Yes
Input Voltage
100 - 240 V
Input Frequency Range
50 - 60 Hz
Input Current
10A
Output
+3.3V@22A, +5V@22A, +12V@62.5A, -12V@0.3A, +5VSB@3A
MTBF
>120,000 Hours
Approvals
CE, cTUVus, TUV, SUD, FCC, CCC, BSMI, EAC
Dimensions
3.39" x 5.91" x 6.29"
Weight
7.40 lbs.
Connectors
1 x 24-pin ATX
1 x 4+4-pin EPS
4 x 6+2-pin PCI-E
9 x SATA
4 x Peripheral
1 x Floppy
Features
Compliance with Intel ATX 12V 2.4 & SSI EPS 12V 2.92 standards
80 PLUS GOLD certified - 90% efficiency under typical load
Single +12V rail Design offers 62.5A of power and includes 4 x PCI-E 6+2 power connectors
Unique 256 color Riing 14 (140mm) RGB fan with multiple lighting modes and built-in memory
Smart Zero Fan: Minimizes undesired noise with 0dB options available
Full modular design with low profile black flat cables
100% 105 degree C / 221 degree F High quality Japanese capacitors.
Intel Skylake's C6 / C7 states & ErP ready
Improvements in Ripple Noise and Extremely Strict Voltage Regulation provides exceptional steady clean power
Over Current, Over Power, Over Voltage, Under Voltage, Over Temperature and Short-Circuit protections
