Ubiquiti Networks NBE-M5-16 5 GHz 16dBi NanoBeam airMAX Bridge

The NBE-M5-16 5 GHz 16dBi NanoBeam airMAX Bridge from Ubiquiti Networks directs RF energy in a tighter beamwidth. NanoBeam maximizes noise immunity by its uniform bandwidth. With focus in one direction, the NanoBeam blocks or spatially filters out noise, so noise immunity is improved. This feature is important in an area crowded with other RF signals of the same or similar frequency.

$129.95

Sold and Shipped By:

Availability

Head Office and Technical Facility 2

Barrie Store 0

Orillia Store 0

Midland Store 0

Quick Specs

airMAX Technology
Atheros MIPS 74Kc, 560 MHz Processor
64MB DDR2, 8MB Flash Memory
1 x 10/100 Ethernet Port
airOS, airView, airControl Software
Power/LAN/WLAN LED Indicators
Quick Assembly
Versatile Mounting
RoHS Compliant
FCC, IC, CE Approved

Wireless

Frequency	5 GHz
Sensitivity	-75 to -96 dBm
Antenna Gain	16 dBi
Transmit Power	23 to 26 dBm

Interface

Inputs/Outputs

1x RJ45 10/100 Mb/s Ethernet PoE (Unspecified)

Hardware

RAM	64 MB
Storage Capacity	8 MB
Processor	560 MHz MIPS 74Kc

Electrical

DC Input Power	VDC at 0.5 A
Power Consumption	6 W

Environmental

Operating Temperature	-40 to 158°F / -40 to 70°C
Operating Humidity	5 to 95%

General

Certifications	CE, FCC, IC, RoHS, as per Manufacturer
Mount Options	Pole, Wall
Dimensions	5.51 x 5.51 x 2.13" / 140 x 140 x 54 mm
Weight	0.71 lb / 0.32 kg
