The NVR502-08B-P8 is a powerful 8-channel PoE network video recorder designed for reliable, high-performance surveillance deployments. Supporting Ultra 265, H.265, and H.264 video compression, it delivers efficient recording while reducing storage requirements without compromising image quality.
Featuring 8 built-in PoE ports for true plug-and-play camera installation, the recorder supports cameras up to 16MP resolution and provides HDMI output up to 4K UHD for detailed monitoring and playback. With advanced decoding capabilities, ONVIF compatibility, ANR technology, and support for up to two hard drives, the NVR502-08B-P8 provides a flexible and dependable solution for commercial, residential, and professional security applications.
Built with intelligent video management features including AI-powered analytics support, smart search, and reliable network performance, the NVR502-08B-P8 is ideal for small to medium-sized surveillance systems requiring easy installation, scalable storage, and advanced monitoring capabilities.
# of #
| Feature | Specification |
|---|---|
| Model | NVR502-08B-P8 |
| Recorder Type | 8-Channel 8 PoE 1U Network Video Recorder |
| Series | Prime Series |
| Video Input | 8 × IP Camera Channels |
| PoE Ports | 8 × Independent PoE Network Interfaces |
| PoE Standard | IEEE 802.3af / IEEE 802.3at |
| Maximum PoE Power | 30 W per port, 130 W total |
| Video Compression | Ultra 265, H.265, H.264 |
| Maximum Recording Resolution | Up to 16MP |
| Incoming Bandwidth | 320 Mbps |
| Outgoing Bandwidth | 160 Mbps |
| Decoding Capability | Ultra 265/H.265: 2 × 16MP @ 30fps, 2 × 12MP @ 30fps, 4 × 4K @ 30fps, 6 × 5MP @ 30fps, 8 × 4MP @ 30fps |
| Live View / Playback | Up to 8 channels synchronous playback |
| HDMI Output | 1 × HDMI, up to 4K (3840 × 2160) @ 30fps |
| VGA Output | 1 × VGA |
| Display Output | HDMI and VGA independent output |
| Hard Drive Bays | 2 × SATA Interfaces |
| Maximum HDD Capacity | Up to 16TB per HDD |
| RAID Support | RAID 1 Supported |
| ANR Support | Yes (Automatic Network Replenishment) |
| Audio Input | 1 × RCA |
| Audio Output | 1 × RCA |
| Two-Way Audio | Supported |
| Alarm Inputs | 8 Channels |
| Alarm Outputs | 2 Channels |
| USB Ports | Front: 1 × USB 2.0; Rear: 1 × USB 3.0 |
| Network Interface | 1 × RJ45 10/100/1000 Mbps Ethernet |
| RS485 Interface | 1 × RS485 |
| ONVIF Support | Profiles S, G & T |
| Remote Users | Up to 128 Users |
| Power Supply | AC 100–240V |
| Power Consumption | ≤20W (without HDD) |
| Operating Temperature | -10°C to +55°C (14°F to 131°F) |
| Operating Humidity | ≤90% RH (non-condensing) |
| Rack Mountable | 1U Rack Mount Design |
| Dimensions | 380 × 322 × 53 mm (15.0 × 12.7 × 2.1 in.) |
| Weight (Without HDD) | ≤2.6 kg (5.73 lbs) |
